Glenwood Springs Metal Shop
The profiles we bend
These 36shapes come straight out of our shop's own profile library — the same drawings and dimensions our fabricators work from at the brake. Every one of them is bent here in Glenwood Springs, in the material and finish your job calls for.
Bring a drawing, a field measurement, or a broken piece off the roof. If the shape isn't on this page, it is almost certainly still something we can bend — this list is what we bend regularly, not the limit of the brake.
Every shape here is bent in the metal and finish your job calls for — See the metal color chart.
Siding Trim
Base Trim
Shop profile P08
- Bends
- 3
- Flat width
- 4 3/4″
- Legs
- 4
Wall Leg 1 1/2″ · Offset 1″ · Slope 1 3/4″ · Drip Leg 1/2″
Ends: Raw / Raw
Combo Track Cover
Shop profile P09
- Bends
- 3
- Flat width
- 10 15/16″
- Legs
- 4
Top Leg 1 5/8″ · Return 1 5/8″ · Slope 6 7/8″ · Toe 13/16″
Ends: Raw / Raw
Double Angle
Shop profile P17
- Bends
- 3
- Flat width
- 6″
- Legs
- 3
Upper Leg 3″ · Step 1″ · Lower Leg 1 1/2″
Ends: Raw / Hem - 1/2″
J Channel
Shop profile P18
- Bends
- 4
- Flat width
- 8″
- Legs
- 3
Front Leg 2″ · Base 1″ · Back Leg 4″
Ends: Hem - 1/2″ / Hem - 1/2″
L Channel
Shop profile P27
- Bends
- 1
- Legs
- 2
Wall Leg 2″ · Base 2″
Available in
- 1″
- 1 1/2″
- 2″
- 3″
- 1 1/2″ × 1 1/2″
Olson Trim
Shop profile P29
- Bends
- 3
- Legs
- 4
Width 2″ · Riser 7/8″ · Base 1″ · Drip Leg 1″
Wainscot & Base Flashing
Shop profile P39
- Bends
- 2
- Legs
- 3
Wall Leg 1 1/2″ · Offset 1″ · Drip Leg 1 1/2″
Eave & Rake Edge
Custom Eave Trim
Shop profile P20
- Bends
- 2
- Legs
- 3
Nail Pad 1 5/8″ · Face 2 1/2″ · Kickout 5/8″
D-Style Drip Edge
Shop profile P02
- Bends
- 4
- Flat width
- 7 5/8″
- Legs
- 4
Nail Pad 2 5/8″ · Overhang 3/4″ · Face 3″ · Kickout 3/4″
Available in
- 3″
Ends: Raw / Hem - 1/2″
Drip Edge
Shop profile P01
- Bends
- 3
- Flat width
- 6 7/8″
- Legs
- 3
Nail Pad 2 5/8″ · Face 3″ · Kickout 3/4″
Available in
- 3″
Ends: Raw / Hem - 1/2″
Eave Flashing
Shop profile P24
- Bends
- 2
- Legs
- 3
Nail Pad 3″ · Face 4 1/2″ · Kickout 1″
Gravel Stop
Shop profile P07
- Bends
- 4
- Flat width
- 8″
- Legs
- 4
Nail Pad 2 1/2″ · Riser 1 3/16″ · Face 3 3/16″ · Kickout 5/8″
Ends: Raw / Hem - 1/2″
Shingle Rake Trim
Shop profile P33
- Bends
- 3
- Legs
- 4
Nail Pad 3″ · Face 4 1/2″ · Step 1″ · Drip Leg 3/4″
Wall Flashing
Endwall
Shop profile P13
- Bends
- 2
- Flat width
- 10″
- Legs
- 2
Wall Leg 5 1/2″ · Roof Leg 4″
Available in
- LG-107
Ends: Raw / Hem - 1/2″
Headwall
Shop profile P12
- Bends
- 2
- Flat width
- 8 1/2″
- Legs
- 2
Wall Leg 4″ · Roof Leg 4″
Ends: Raw / Hem - 1/2″
Sidewall
Shop profile P11
- Bends
- 2
- Flat width
- 7 1/2″
- Legs
- 2
Wall Leg 4″ · Roof Leg 3″
Ends: Raw / Hem - 1/2″
Sidewall Flashing - Kicked
Shop profile P34
- Bends
- 3
- Legs
- 4
Wall Leg 4″ · Roof Leg 3″ · Riser 11/16″ · Lip 3/4″
Z Flashing
Shop profile P41
- Bends
- 2
- Legs
- 3
Nail Pad 1 1/2″ · Riser 3/4″ · Lip 1 1/2″
Door & Window
Door Jamb
Shop profile P22
- Bends
- 3
- Legs
- 4
Face 7 1/4″ · Base 1 5/8″ · Riser 2″ · Lip 1 5/8″
Available in
- 3 1/2″
- 7 1/4″
- 9 1/4″
Door Post Trim
Shop profile P21
- Bends
- 1
- Legs
- 2
Width 1 1/2″ · Face 5 1/4″
Available in
- 3 1/2″
- 5 1/4″
- 7 1/4″
Window Drip Cap
Shop profile P40
- Bends
- 2
- Legs
- 3
Wall Leg 1 1/2″ · Width 1 1/2″ · Kickout 5/8″
Available in
- 1″
- 1 1/2″
Accessory
Snowguard
Shop profile P35
- Bends
- 3
- Legs
- 4
Foot 1″ · Slope 3 3/8″ · Wall Leg 2 7/8″ · Foot 1″
Top Mount Rack Cover
Shop profile P37
- Bends
- 3
- Legs
- 4
Top Leg 1″ · Width 3 1/2″ · Slope 4″ · Drip Leg 1 5/8″
Fascia & Trim
Fascia
Shop profile P05
- Bends
- 2
- Flat width
- 7 1/2″
- Legs
- 2
Face 5 1/2″ · Underhang 1 1/2″
Available in
- 7 1/2″
- 5 1/2″
- 3 1/2″
- 4″
Ends: Raw / Hem - 1/2″
Fascia - Stepped
Shop profile P06
- Bends
- 6
- Flat width
- 7 7/8″
- Legs
- 6
Face 3″ · Step 5/8″ · Lower Face 1 1/2″ · Underhang 1″ · Riser 1/2″ · Lip 3/4″
Ends: Raw / Hem - 1/2″
Receiver / Counterflashing
Rake Receiver
Shop profile P16
- Bends
- 7
- Flat width
- 12 5/16″
- Legs
- 6
Roof Leg 3″ · Receiver Return 1 3/16″ · Riser 1/2″ · Width 3″ · Face 3″ · Kickout 5/8″
Ends: Hem - 1/2″ / Hem - 1/2″
Sidewall Receiver
Shop profile P14
- Bends
- 4
- Flat width
- 11 1/2″
- Legs
- 4
Wall Leg 4″ · Roof Leg 3″ · Receiver Return 1 1/2″ · Receiver Leg 2 1/2″
Ends: Raw / Hem - 1/2″
Ridge & Peak
Peak Trim
Shop profile P30
- Bends
- 1
- Legs
- 2
Roof Leg 4″ · Roof Leg 6″
Available in
- 4 × 6
Ridge Cap
Shop profile P32
- Bends
- 3
- Legs
- 4
Roof Leg 7″ · Rib 1/2″ · Rib 1/2″ · Roof Leg 7″
Available in
- 7″
- 8″
- 9″
- 10″
Valley
V Valley
Shop profile P04
- Bends
- 3
- Flat width
- 10″
- Legs
- 2
Valley Leg 4 1/2″ · Valley Leg 4 1/2″
Ends: Hem - 1/2″ / Hem - 1/2″
W Valley
Shop profile P03
- Bends
- 5
- Flat width
- 11 3/8″
- Legs
- 4
Valley Leg 4″ · Rib 1 3/16″ · Rib 1 3/16″ · Valley Leg 4″
Available in
- 9″
- 14″
Ends: Hem - 1/2″ / Hem - 1/2″
Base & Guard
Rat Guard & Base Angle
Shop profile P19
- Bends
- 3
- Flat width
- 7 1/2″
- Legs
- 3
Wall Leg 3″ · Base 1 1/2″ · Guard 2 1/2″
Ends: Raw / Hem - 1/2″
Cap & Coping
Cap Metal
Shop profile P10
- Bends
- 6
- Flat width
- 12 1/2″
- Legs
- 5
Kickout 3/4″ · Face 3″ · Width 4″ · Face 3″ · Kickout 3/4″
Ends: Hem - 1/2″ / Hem - 1/2″
Corner Trim
Outside Corner Trim
Shop profile P28
- Bends
- 5
- Flat width
- 12″
- Legs
- 4
Offset 1″ · Side 4 1/4″ · Side 4 1/4″ · Offset 1″
Available in
- 4 1/4″
- 3 × 3
Ends: Hem - 3/4″ / Hem - 3/4″
Soffit
Soffit Panel
Shop profile P15
- Bends
- 5
- Flat width
- 8 1/2″
- Legs
- 5
Top Flange 1″ · Side 1″ · Panel 4″ · Side 1″ · Top Flange 1″
Ends: Hem - 1/2″ / Raw
Transition
Transition
Shop profile P38
- Bends
- 1
- Legs
- 2
Wall Leg 3″ · Roof Leg 6 1/2″
Available in
- Inside
- Outside
Bending something that isn't here? The shop works from your drawing or your field measurements. Send us your drawing.
Bent in the metal you specify
Every profile on this page can be run in copper, brass, zinc, architectural steel with a Kynar 500 / PVDF finish, aluminum, galvanized, Galvalume, or stainless. We don't substitute: when the spec says 20 oz copper, that is what leaves the shop.
Painted profiles are run in the coil colors on our metal color chart — 50+ finishes including metallics, wood grains and bare mill products.
Same-day on most shapes
Drop your order off in the morning and pick it up by mid-day. No overnight freight, no waiting on a supplier two states away — which is why other roofing companies in the valley use our shop as their shop.
More about the shop: custom metal fabrication.
Need a custom profile bent?
Send a quick note and one of our estimators will follow up. Prefer to talk? Call 970-945-8048.
